How To Wire The LED Ceiling Lamp

Views: 13     Author: Site Editor     Publish Time: 2019-11-12      Origin: Site

1. Choose The Position

The first thing to install the ceiling lamp is to determine the installation position of the ceiling lamp. For example, the ceiling lamp in the living room, dining room, and kitchen is preferably installed in the middle, so that the light is more average in each position. In the bedroom, consider the influence of the mosquito net and light to sleep, ceiling lamp should not be installed on the top of the bed. In addition, the ceiling lamp needs to select the wall or ceiling that can withstand the weight of the ceiling lamp for installation. Try not to choose the wooden wall surface to avoid danger of falling after long time.


2. Disassemble Ceiling Lamp Mask

Remove the ceiling lamp mask firstly, Under normal circumstances, the ceiling lamp mask has two fixing ways of the rotation and the buckle. When disassembling, pay attention to avoid the damage of the ceiling lamp. After the mask is removed, the lamp is also removed to prevent the lamp from being broken during installation.


3. Install The Base

Place the base in the predetermined installation position, mark the wall with a pencil, then take the base, drill with the electric drill at the marked position, and then install the expansion bolt in the hole for fixing base, pay attention to the diameter and the depth of the hole to match the specifications of bolts. Then put the base back to the predetermined position and fix it.


terminal connector


4. Connect The Wire

After fixing the base, you can connect the power cable to the terminal connector of the ceiling lamp. It should be noted that the two wires connected to the power cable of the ceiling lamp should have good electrical contact, and should be wrapped with black rubber separately. Keep a certain distance, if possible, do not put the two wire heads under the same piece of metal to avoid short circuit, which is dangerous.


5. Install The Masks And Hanging Ornaments

After connecting the wires, you can try to power on. If everything is normal, you can turn off the power supply and install the mask of the ceiling lamp. And the living room ceiling lamp also needs to be equipped with a series of hanging ornaments, because each ceiling lamp charm is different, we should refer to the product manual for the specific installation method, The hanging ornaments will generally remain, and can be stored after installation. It can be replaced when needed later.

As the heat of home decoration continues to heat up, the changes in ceiling lamps are also changing with each passing day. They are no longer confined to the previous single lamps, but are diversified. They not only absorb the luxury and style of chandeliers, but also adopt the ceiling-mounted installation method, which avoid the shortcomings of the small room can not be installed with large luxury lighting.


terminal connector



Where And How Is The Control Line Of The Ceiling Lamp Connected?

Before we pick up, we must first distinguish the nature of the three wires in the ceiling lamp. The three wires are: the incoming wire of the fire wire L, the incoming wire of the neutral wire N, and the grounding protection wire PE. The three wires are distinguished according to the color of the wire. Fire line L red, zero line N blue, ground line PE yellow green double color line. Due to the large number of top lamp manufacturers, the wire color and the standard color are quite different most of time. According to experience, the following ways can be distinguished: 1 As long as it is a two-color line, it is generally grounded PE line; 2 then look for hot color lines, such as brown, yellow, etc., hot color lines are generally fire line L; cool color lines, such as green, light blue, white, etc., generally Zero line N. Connect the switch wire in the roof junction box (or jack hole) to the fire hole of the ceiling lamp; the neutral wire and the ground wire are connected to the corresponding hole of the ceiling lamp. If there is no ground lead wire, you can also do not pick up, which not affect the use of lamps.
