The electrical connector is a kind of accessory product used to realize electrical connection. With the development of the electronic industry, the use of electrical connectors is more and more, and the types are more and more as well, such as small wire connectors, electrical wire connectors, cable connectors, terminal connectors, and so on. Plastic insulating materials and conductive components of crimp wire connectors are directly related to the quality of electrical connectors. Failure of any electrical connector will lead to failure of the whole system engineering. Here are three common forms of fatal faults in electrical connectors.
The metal conductor inside the electrical connector is the core part of the wire termination connectors It transmits the voltage, current or signal from the external wire or cable to the contacts corresponding to its matching connector. Therefore, the contact parts must have excellent structure, stable and reliable contact retention and good conductivity. Due to unreasonable contact structure design, wrong material selection, unstable die, excessive processing size, rough surface, unreasonable surface treatment process such as heat treatment and electroplating, improper assembly, poor storage and use environment and improper operation, all of these will cause poor contact.
The function of the insulator is to keep the contacts in the correct position and to insulate the contacts from the contacts and the contacts from the housing. Therefore, the insulation must have excellent electrical properties, mechanical properties and process forming properties. In particular, with the wide use of miniaturized electrical connectors, the effective wall thickness of the insulator is getting thinner and thinner. This puts more stringent requirements on injection mold precision and molding processes of the insulation materials. Due to the presence of metal excesses on the surface or inside of the insulator, organic material precipitates and harmful gas adsorption film and surface water film fuse to form ionic conductive channels, moisture absorption, mildew, insulation material aging and other reasons, It will cause short circuit, leakage, breakdown, low insulation resistance and other insulation problems.
Insulators not only play an insulating role, but also provide accurate protection for extended contacts. They also have the functions of installation, positioning and locking and fixing on equipment. Poor fixing can affect contact and cause instantaneous power failure or product disintegration. Disintegration refers to the abnormal separation between plugs and sockets and between pins and sockets caused by unreliable structure due to material, design, process and other reasons, which will result in serious consequences of the interruption of power transmission and signal control in the control system. Due to unreliable design, wrong material selection, improper selection of forming process, poor quality of heat treatment, die, assembly, welding and other processes, inadequate assembly will cause poor fixation.
In addition, due to coating peeling, corrosion, rupture, rough contact parts processing, deformation and other reasons caused by poor appearance, due to positioning and locking with poor size, poor consistency of processing quality caused by a large number of reasons is also very common and frequently-occurring. Generally, these kinds of faults can be found and eliminated in time in the process of inspection and use.
