1.When selecting the wire, please check if the wire size is within the applicable range of the terminal specification.
2. Please check if the outer diameter of the wire is within the applicable range of the terminal specification.
3. Make sure that the crimping tool used for production is suitable for this terminal
4. Ensure that the crimping tool used for production is properly maintained
5. Please check whether the wire stripping length is appropriate
6. Make sure the core is not damaged during the peeling process
7. After crimping, please check if the wire core is inside the metal wire.
8. Ensure that the feeder and all safety equipment are properly installed
9. Ensure that the terminal crimp height has been adjusted to a specific range
10. Please check whether the insulation part has been adjusted to the normal shape without damaging the wire insulator and core.
11. Make sure that the wire end terminals that have been crimped have proper taper hole amount.
12. Please check that the non insulated wire terminals that have been crimped have the proper cut-off length at the front and the end of the terminal.
13. After crimping, please check if there is too much "preef" in the wire section.
14. After crimping, please make sure that the buckle is not damaged.
15. After crimping, please make sure that the connecting part of the terminal does not deform.
16. After crimping, please check that the terminal does not have excessive bending.
17. After crimping, please check that the machine wire terminals does not have too much distortion.
18. Make sure the wires are crimped in place.
After the insulation is crimped, the left and right sides shall be equal.
The insulating part can be formed to effectively grasp the wire insulator.
The insulation will not tear the insulation and damage the core of the wire.
The insulation part of the wire insulator will not be exposed.
After the metal wire is crimped, the left and right sides shall be equal.
The wire should be closed tightly and the core should not be exposed here.
There will be no cracks in the wire.
There won't be too many "preef" in the wire.
Both sides of the wire part will not touch the bottom of the wire crimp terminals.
The optimum wire position is that the wire core is 0.5-1.0mm beyond the wire portion, and the wire insulator should be in the middle of the wire portion and the insulation portion. The key point is that the wire stripping length is correct, so that the wire position is ensured.
