Feature Of Wire Terminal

Views: 10     Author: Site Editor     Publish Time: 2019-10-18      Origin: Site

Wire Terminal Definition

1. Wire terminal is a product of copper alloy processed by high-speed continuous stamping die or single engineering die, and terminal is the core part of connector to complete electrical connection function.


2. Contact pairs are generally composed of a male contact and a female contact, and complete Electrical connection by the insertion of the female and male contact.


3. male contacts are generally made of brass or phosphor bronze. The female contact, that is, socket contact, is a key component of the contact pair. It relies on the elastic structure to elastically deform when it is inserted into the pin, and generates elastic force to form close contact with the male contact member to complete the connection.



 Wire terminal

Shape of Terminal

Ring Terminal

Ring terminals are round end terminals, which can easily connect the screw or the double head bolt. Ring terminals, also known as ring connectors, with various sizes. It is very important that the ring terminal is compatible with wire gauge and double-head bolt size. Ring terminals are welded or crimped to the wires. Work in the form of non-insulated or insulated.



Spade Terminal

Because of the shape of the terminal, the spade terminal is also called fork terminal or spade connector. The spade terminal has a variety of sizes, depending on the specifications of the wire and the size of the double-head bolt. The open-ended spade terminal is easy to use and can easily fix the screw or remove it from the screw. It is especially suitable for installing wire harness projects with narrow space. Work in the form of non-insulated or insulated.



Hook Terminals

Similar to Spade Terminal, Hook Terminals can be easily used with the open end (imagine a compact version of Captain Hook). The insulated or non-insulated hook terminals produced can provide simple and durable connection for various projects.



 Wire terminal


A Quick-Disconnect Terminal

Quick disconnection terminals can provide reliable and convenient use, can easily connect and disconnect two wires. Common in automobiles, consumer products and industries. Non-insulated or insulated quick disconnection terminals produced can provide stable and durable connections.



Bullet Terminal

Bullet terminal, also known as bullet connector, can realize simple, reliable and safe connection. It's also easy to disconnect. Bullet terminals are connected with male and female connectors to form high quality connections. Connections to bullet terminals help prevent corrosion and other potentially harmful substances from entering the harness.



Butt Terminals

Butt terminal connects or terminates one or more wires. Butt terminals help prevent cutting and abrasion. This extra protection helps prevent corrosion, moisture and other adverse factors. Because of the ability to match and connect wires, butt terminals can be used as a simple solution to extend wires. Simply install each wire at the open end of the connector, and then crimp the two ends of the terminal to fix the connection.



Flag Terminals

Flag terminals (also known as flag connectors) provide secure and convenient connections. Flag terminals work well in narrow spaces and in situations where fast disconnection is too large. Provide easy and quick disconnection and connection. Work in the form of non-insulated or insulated.





Wire Terminal material

Commonly used are phosphorus copper, copper, bronze, brass, beryllium copper, stainless steel and other metals
